Titanium Plate Aerator

Titanium Plate Aerator

Titanium alloy aerators are widely used in municipal sewage, industrial effluent, seawater aquaculture, and high-end water treatment. They offer corrosion resistance, high-temperature endurance, high oxygen utilization, and long service life.

Product Introduction

Titanium microporous plate aerators are high-performance gas diffusion devices designed for efficient oxygen transfer in wastewater treatment, industrial effluent treatment, seawater aquaculture, and other demanding water treatment applications.

Manufactured from high-purity titanium or titanium alloy, the aerator utilizes a sintered porous titanium plate with uniformly distributed micropores. Compressed air passes through the porous structure and is dispersed into fine bubbles, significantly increasing the gas-liquid contact area and improving oxygen transfer efficiency.

Compared with conventional ceramic, rubber membrane, and plastic aerators, titanium aerators offer superior corrosion resistance, mechanical strength, durability, and long-term operational stability.

They are particularly suitable for corrosive, high-salinity, high-temperature, and high-pressure environments where conventional aeration materials may have limited service life.

Working Principle

Compressed air enters the titanium aerator through the pipeline connection and passes through the microporous titanium plate.

The uniformly distributed pores generate a large number of fine bubbles.

These microbubbles provide:

Larger gas-liquid contact area

Longer bubble residence time

Improved oxygen transfer efficiency

Higher oxygen utilization

Reduced energy consumption

Because the bubbles rise more slowly than larger bubbles produced by conventional aerators, oxygen has more time to dissolve into the water.

Microbubble Aeration Advantages

Smaller Bubble Size
→ Larger gas-liquid contact area

Slower Rising Velocity
→ Longer oxygen transfer time

Higher Oxygen Dissolution Efficiency
→ Improved energy utilization

Product Structure

A typical titanium microporous plate aerator consists of:

Titanium Body

Manufactured from high-purity titanium or titanium alloy, providing excellent corrosion resistance and mechanical strength.

Microporous Titanium Plate

Produced through powder metallurgy and high-temperature sintering technology.

The porous structure provides:

Uniform pore distribution

Stable bubble generation

High gas permeability

Excellent mechanical strength

Typical pore size:

20–100 μm

Connection Interface

Standard connection:

R1/2" Threaded Connection

Other connection types can also be customized according to customer requirements.

Technical Specifications

Model Air Outlet Diameter Height Connection Service Area Oxygen Utilization Rate
CS-100 Ø100 mm 60 mm R1/2" 0.4 m² 32.22–45.33%
CS-150 Ø150 mm 68 mm R1/2" 0.8 m² 32.22–45.33%
CS-200 Ø200 mm 83 mm R1/2" 1.0 m² 32.22–45.33%

Material Options

Titanium Gr1

Titanium Gr2

TA1

TA2

Customized titanium alloys are available for special operating environments.

Key Advantages

Excellent Corrosion Resistance

Titanium naturally forms a dense and stable oxide film that provides excellent resistance to corrosion.

Titanium aerators are suitable for environments containing:

Chloride ions

Seawater

Acidic wastewater

Alkaline wastewater

High-salinity water

Chemical process liquids

This makes titanium aerators particularly suitable for industrial wastewater treatment systems where conventional EPDM or plastic aerators may degrade rapidly.

High Oxygen Transfer Efficiency

The microporous titanium structure generates fine and uniform bubbles.

Compared with large-bubble aeration systems, microbubble aeration provides:

Larger gas-liquid contact area

Longer bubble residence time

Higher oxygen dissolution efficiency

Improved treatment performance

This can help reduce the energy consumption of aeration systems.

High Temperature and Pressure Resistance

Titanium has excellent mechanical properties at elevated temperatures and high-pressure environments.

The aerator is suitable for:

High-temperature industrial wastewater

Deep-water aeration

High-pressure aeration systems

Chemical processing environments

Unlike polymer membrane aerators, titanium porous structures maintain good mechanical stability under demanding operating conditions.

Long Service Life

Titanium provides excellent resistance to corrosion and material degradation.

Under appropriate operating conditions, titanium aerators can achieve a significantly longer service life than conventional aeration materials.

Advantages include:

Reduced replacement frequency

Lower maintenance requirements

Stable long-term performance

Reduced lifecycle operating costs

Uniform Bubble Distribution

The sintered titanium porous structure contains uniformly distributed micropores.

This allows compressed air to be evenly dispersed across the aeration surface, producing consistent bubble distribution.

Benefits include:

Stable oxygen transfer

Improved mixing performance

Reduced localized oxygen deficiency

More efficient aeration coverage

High Mechanical Strength

Compared with ceramic aerators, titanium porous plates provide superior mechanical strength and impact resistance.

They are less susceptible to cracking during:

Transportation

Installation

System maintenance

High-pressure operation

Easy Maintenance

Titanium porous aerators have good resistance to fouling and corrosion.

If cleaning is required, performance can often be restored through appropriate cleaning methods such as:

Water flushing

Chemical cleaning

Acid cleaning under controlled conditions

Ultrasonic cleaning

Cleaning procedures should be selected according to the actual operating medium and contamination type.

Application Areas

Municipal Wastewater Treatment

Titanium microporous aerators can be used in municipal wastewater treatment systems including:

Activated sludge processes

Oxidation ditches

Aeration tanks

MBR systems

Biological treatment systems

The fine bubble distribution improves oxygen transfer efficiency and supports stable biological treatment.

Industrial Wastewater Treatment

Suitable for demanding industrial wastewater environments such as:

Chemical wastewater

Electroplating wastewater

Printing and dyeing wastewater

Pharmaceutical wastewater

High-salinity wastewater

Acidic or alkaline wastewater

Titanium's corrosion resistance provides significant advantages in aggressive chemical environments.

Seawater Aquaculture

Titanium aerators are particularly suitable for seawater applications because of their excellent resistance to chloride corrosion.

Applications include:

Marine aquaculture

Fish farming systems

Shrimp farming

Seawater circulation systems

Marine research facilities

The efficient oxygen transfer helps improve dissolved oxygen levels and maintain water quality.

Deep Water Aeration

Titanium porous aerators have strong mechanical stability and can be used in deep-water aeration systems.

Typical applications include:

Deep reservoirs

Aquaculture tanks

Industrial water treatment tanks

Deep biological treatment reactors

Chemical and Electrochemical Industries

Titanium aerators can also be used in specialized chemical processing environments requiring corrosion-resistant gas distribution systems.

Applications may include:

Chemical reactors

Oxidation systems

Electrochemical processes

Gas-liquid reaction systems

Comparison with Conventional Aerators

Feature Titanium Microporous Aerator EPDM Membrane Aerator Ceramic Aerator Plastic Aerator
Corrosion Resistance Excellent Moderate Good Limited
Mechanical Strength Excellent Moderate Brittle Moderate
High Temperature Resistance Excellent Limited Good Limited
High Pressure Resistance Excellent Moderate Moderate Limited
Service Life Long Moderate Moderate Shorter
Seawater Resistance Excellent Limited Good Limited
Chemical Resistance Excellent Moderate Good Limited
Customization High Moderate Limited High

Customization Options

We can manufacture customized titanium aerators according to customer requirements.

Customization options include:

Aerator diameter

Aeration area

Titanium grade

Pore size

Gas flow capacity

Connection type

Thread specification

Flange connection

Operating pressure

Custom shapes

Special corrosion-resistant designs

OEM and custom engineering solutions are available based on project requirements.

Why Choose Titanium Aerators?

Titanium microporous aerators combine the advantages of advanced porous material technology and titanium's excellent corrosion resistance.

They offer:

High oxygen transfer efficiency

Uniform microbubble generation

Excellent corrosion resistance

High mechanical strength

High temperature resistance

High pressure resistance

Long service life

Low maintenance requirements

Suitable for seawater and high-salinity environments

Customizable design

Frequently Asked Questions

What material is used for the aerator?

The aerator is primarily manufactured from high-purity titanium or titanium alloy, such as Gr1 or Gr2 titanium.

What is the pore size of the titanium porous plate?

Typical pore sizes range from approximately 20 to 100 μm, depending on the required aeration performance.

Can titanium aerators be used in seawater?

Yes. Titanium has excellent resistance to chloride corrosion and is highly suitable for seawater and marine aquaculture applications.

Can the aerator be customized?

Yes. Diameter, pore size, connection type, titanium grade, and aeration capacity can be customized according to customer requirements.

How is the titanium porous plate manufactured?

The porous titanium plate is produced using powder metallurgy and high-temperature sintering technology to create a stable microporous structure.

Are titanium aerators suitable for industrial wastewater?

Yes. They are particularly suitable for corrosive, high-salinity, acidic, alkaline, and high-temperature industrial wastewater environments.
