Titanium Powder Sinter Filter
Material:Pure titanium
Diameter:OD18-OD80mm
Wall thickness:2.0-3.0mm
Length can reach 1200mm no welding
Pore size:1-180microns
Product Introduction
Titanium powder sintered filter is a porous metal filtration element manufactured from high-purity titanium powder through a controlled compaction and high-temperature sintering process.
This process creates a rigid porous structure with uniform pore size, stable geometry, and excellent mechanical strength.
These filters are widely used for gas and liquid filtration in demanding industrial environments, especially where corrosion resistance and high temperature stability are required.
Product Specification
Standard Dimensions
Item | Specification |
Size | OD60 × WT 2.5–3.0 × L400 mm (customizable) |
Shape | Tube / disc / plate / customized |
Pore Size | 0.5 – 100 microns |
Porosity | 30% – 40% |
Performance Characteristics
High filtration efficiency
Stable pore structure
High mechanical strength
Long service life
Easy backwashing / regeneration
Manufacturing Process
1. Raw Material Preparation
Titanium powder
Sintering additives
Optional alloying agents
2. Powder Mixing
Titanium powder is uniformly blended with additives to achieve controlled porosity and structure.
3. Forming (Pressing)
The mixed powder is compacted into the desired shape using precision molds.
4. Sintering
The compacted structure is sintered at high temperature to create:
Strong metallurgical bonding
Controlled porous network
Stable mechanical integrity
5. Machining / Cutting
Sintered parts are processed into final dimensions according to application requirements.
6. Finishing
Includes:
Surface polishing
Cleaning
Optional surface treatment for enhanced performance
Key Advantages
High Temperature Resistance
Titanium maintains structural stability in high-temperature environments without deformation or degradation.
Excellent Corrosion Resistance
Resistant to:
Strong acids
Alkalis
Chloride environments
Harsh chemical media
Precise Filtration Performance
Controlled pore size ensures:
High particle retention efficiency
Stable flow characteristics
Reliable separation performance
High Mechanical Strength
Unlike polymer filters, sintered titanium filters:
Do not collapse under pressure
Maintain structural integrity over long-term use
Long Service Life
Reusable through backwashing, cleaning, and regeneration.
Applications
Chemical Industry
Acid and alkali filtration
Catalyst recovery
Chemical process filtration
Pharmaceutical Industry
Sterile filtration
High-purity liquid processing
Food & Beverage
Beverage clarification
Gas filtration in production systems
Oil & Gas Industry
Gas purification
Fluid separation systems
Corrosive media filtration
Connectors & System Integration
Titanium sintered filter connectors are:
Made from titanium material
Designed for high temperature and corrosion environments
Used for integration into filtration assemblies
Compatible with industrial piping systems
