Asme B16.5 Pn40 Blind Plate Titanium Forged Flange
1/2"-80"Titanium blind plate flange,ansi b16.5 BL titanium flange,blind plate titanium flange. Pressure Class: 0.6~32Mp (DIN) PN6,PN10,PN16,PN25 though PN250 (ASNI) CL150,CL300,CL600,CL900,CL1500 MOQ 1pc
Product Introduction
TITANIUM FLANGES are made of non-ferrous metaltitanium or titanium alloys. And they are a kind of accessory which make the pipe and pipe connected to each other.
There are holes in titanium flanges and bolts make two titanium flanges connected to each other. Titanium flanges can be made by casting, threaded connection or welding.flange joint includes a pair of titanium flanges, a gasket, a number of bolts and nuts. The gasket is put between the contact surfaces of two titaniun flange. After the bolts are tightened,the specific pressure on gasket are up to a certain value, then the gasket are out of shape and fill in contacting surface of two titanium flanges in order to seal flange joint closely.
SPECIFICATION
| Dimensions | ASME B16.5, ANSI B16.5, ASME B16.47 Series A, ASME B 16.47 Series B |
| Size | 1/2" NB to 36" NB in 150LBS, 300LBS, 600LBS, 900LBS, 1500 LBS, 2500 LBS |
| Grade | Gr. 1, Gr. 2, Gr. 3, Gr. 5, Gr. 7, F1, F2, F3, F5, F7 |
| Standard | ANSI B16.5, ASTM B16.5, ASME B16.47, JIS B2220, DIN2627-2628, AWWA ASTM A182, AND ASME SA182 |
Pressure Class | PN0.25~32Mpa |
| (DIN) PN6 PN10 PN16 PN25 though PN250 | |
| 150# 250# 300# 400# 500# 600# 900# 1500# 2500# | |
Flange surface | FF RF TG RJ MFM |
Hot Tags: asme b16.5 pn40 blind plate titanium forged flange, China, manufacturers, suppliers, factory, customized, wholesale, low price, in stock
