Titanium Clad Tubesheets

Titanium clad tubesheets are critical components in heat exchangers and pressure equipment, combining a structural base metal (carbon steel or stainless steel) with a corrosion-resistant titanium layer.

This bimetallic design delivers:

• The strength and cost-efficiency of steel

• The excellent corrosion resistance of titanium

They are widely used in chemical processing, oil & gas, power generation, and marine systems, especially in environments prone to pitting, crevice corrosion, and stress corrosion cracking.

Product Structure

Base Material: Carbon steel / Stainless steel

Cladding Layer: Titanium (Gr1, Gr2, Gr7, Gr12)

Cladding Type: Single-side or double-side

Also known as:

Titanium cladding plate

Titanium-steel composite plate

Metallic laminated composite

Standards

Clad Plate Standard: ASTM B898

Titanium: ASTM B265

Base Materials:

• ASTM A516 / A515 / A266

• ASTM A572 / A709

• ASTM A387 / A240

Manufacturing Techniques

• Explosive Bonding

• Hot Rolling Bonding

• Cold Rolling Bonding

These processes ensure:

• Strong metallurgical bonding

• High interface strength

• Long-term reliability

Specifications

Cladding Thickness: 0.5 mm – 16 mm

Plate Size: up to 2 m × 6 m (customizable)

Max Drilling Depth: up to 1000 mm

Customization: Available based on drawings

Processing & Machining Capabilities

High-precision machining is essential for tubesheet performance:

CNC drilling and deep-hole drilling

Tight tolerance control for:

• Tube hole spacing

• Hole diameter

• Verticality and surface finish

Advanced equipment ensures:

Improved heat transfer efficiency

Accurate assembly

Enhanced operational reliability

Key Features

1. Excellent Corrosion Resistance
   Titanium layer protects against aggressive media, including seawater and chemicals

2. High Structural Strength
   Steel base provides strong mechanical support

3. Cost-Effective Solution
   Reduces material cost compared to solid titanium

4. Resistance to Localized Corrosion
   Superior performance against:

   Pitting

   Crevice corrosion

   Stress corrosion cracking

5. Long Service Life
   Reduced maintenance and replacement frequency

Applications

1. Heat Exchangers

Chemical processing systems

Seawater desalination plants

Industrial cooling systems

2. Pressure Vessels

Oil & gas equipment

Chemical reactors

3. Piping Systems

Corrosive fluid transport

Petrochemical and chemical industries

4. Power Generation

Boilers

Condensers

Thermal systems

5. Marine & Offshore

Seawater cooling systems

Offshore platforms

Advantages Over Solid Titanium
