Titanium Bolt
Materials: Pure Titanium and Alloy Titanium
Other materials: Gr1,Gr2,Gr5 Gr7,Gr9,Gr12 etc
Standard: DIN933
Size: M5----M36,1/4"---2 3/4"
Length:2 1/4"---20",50mm---6000mm
Product Introduction
Our titanium bolts' outstanding strength-to-weight ratio is one of its main benefits. Steel is around 50% heavier than titanium. Applications where decreasing weight is essential, such the manufacturing of sports equipment, automobiles, and airplanes, may be significantly impacted by this weight reduction. Titanium bolts can help reduce weight without sacrificing performance or structural integrity.
The high corrosion resistance of our titanium bolts is another noteworthy benefit. The surface of titanium naturally develops an oxide layer that serves as a barrier against the elements. Titanium is extremely corrosion-resistant thanks to this oxide layer, even in harsh settings where it is exposed to moisture, seawater, or chemicals. Titanium bolts are therefore perfect for use in marine settings, offshore structures, or in any business.
DIN933 Titanium Bolt is a titanium fastener with metric threading and a hexagonal head. DIN933 is a standard specification for hexagon head bolts made of various materials, including titanium. Titanium bolts are widely used in a variety of applications due to their high strength, corrosion resistance, and lightweight properties. The specify the dimensional requirements for the bolt head, shank, thread, and length. The standard also provides specifications for the thread pitch, tolerance, and surface finish. DIN933 titanium bolts typically have a hexagon head and are threaded along the entire length of the shank.
Because of titanium characteristics, such as light-weight, high strength, low density, anti-rust, corrosion resistant, high temperature resistant, low-temperature resistance, etc., titanium bolts are mostly used in military industries, such as aviation, medical, chemical industries, and other special environments.
Stock
1. Grade: gr2, gr3, gr5 gr7 gr9 and gr12
2. Size: M2-M30 Gr2 and Gr5 DIN912, DIN931 and DIN933
3. Titanium color, green, blue, gold, black, purple.
4. Pitch:1.0/1.25 hex head titanium gr2 bolt in stock
5. Features: Lightweight, Low density, good acid and alkali resistance, high corrosion resistance, excellent mechanical strength, good thermal and hypothermia stability
4. Certification: ISO9001:2015
5. Standard; DIN912, DIN914,DIN6921,DIN933,DIN7985,DIN965,DIN7991
6, Applications: industry, automobile, bicycle, motorcycle, and medical implants.
Physical Properties
Grade | Tensile strength MPA | Yield strength MPA | Elongation % |
Gr1 | 240 | 170 | 24 |
Gr2 | 345 | 275 | 20 |
Gr4 | 550 | 483 | 15 |
Gr5 | 895 | 828 | 10 |
Gr7 | 400 | 275 | 18 |
Gr9 | 620 | 483 | 15 |
Gr12 | 483 | 348 | 18 |
Gr23 | 793 | 759 | 10 |
Chemical composition
Grade | Fe Max | O Max | N Max | C Max | H Max | Pd Max | Al Max | Va Max | Ni Max | Mo Max |
/ | Wt % | Wt % | Wt % | Wt % | Wt % | Wt % | Wt % | Wt % | Wt % | Wt % |
Gr1 | 0.2 | 0.18 | 0.03 | 0.08 | 0.015 | |||||
Gr2 | 0.3 | 0.25 | 0.03 | 0.08 | 0.015 | |||||
Gr4 | 0.5 | 0.4 | 0.05 | 0.08 | 0.015 | |||||
Gr5 | 0.4 | 0.2 | 0.05 | 0.08 | 0.015 | 5.5-6.7 | 3.5-4.5 | |||
Gr7 | 0.3 | 0.25 | 0.03 | 0.08 | 0.015 | 0.12- 0.25 | ||||
Gr9 | 0.25 | 0.15 | 0.03 | 0.08 | 0.015 | 2.5-3.5 | 2.0-3.0 | |||
Gr12 | 0.3 | 0.25 | 0.03 | 0.08 | 0.015 | 0.6-0.9 | 0.2-0.4 | |||
Gr23 | 0.25 | 0.03 | 0.03 | 0.08 | 0.0125 | 5.5-6.5 | 3.5-4.5 | |||
Ti | Balance | |||||||||
