MMO copper cored titanium anode
Specification:
copper cored diameter is 2mm
titanium thickness is 0.5mm
Product Introduction
Product Overview
Titanium-clad copper wire is a composite material combining the excellent electrical conductivity of copper with the superior corrosion resistance of titanium. It is widely used in cathodic protection systems and electrochemical applications requiring high conductivity and long service life.
Base Material Structure
Core Material:
T2 Pure Copper
Cladding Material:
Industrial Pure Titanium
Titanium Cladding Thickness:
0.5 mm – 0.8 mm (customizable)
Core Diameter Options
2 mm
3 mm
4 mm
Other sizes available upon request
Finished Product Diameter: Φ3 mm – Φ5.0 mm
Length: Up to 100 meters
Standard: ASTM B863
Coating Options (MMO Coating)
RuO₂ + IrO₂ + X
(Ruthenium Oxide + Iridium Oxide)
Suitable for general cathodic protection applications
IrO₂ + Ta₂O₅ + X
(Iridium Oxide + Tantalum Oxide)
Designed for high-performance and extended-life applications
Key Features
Excellent Corrosion Resistance
Titanium cladding provides outstanding resistance in seawater, acidic, and electrolytic environments.
High Electrical Conductivity
Copper core ensures low electrical resistance and efficient current transmission.
Extended Service Life
Composite structure significantly increases durability, especially in aggressive environments.
Energy Efficiency
Low internal resistance improves current efficiency and reduces power consumption.
Application Flexibility
Suitable for both low-voltage systems and large-scale cathodic protection networks.
Technical Parameters
| Parameter | Details |
|---|---|
| Core Diameter | 2 mm / 3 mm / 4 mm (customizable) |
| Titanium Thickness | 0.5 – 0.8 mm |
| Length | ≤ 100 m |
| Coating Type | Ru-Ir or Ir-Ta |
| Electrical Resistance | 7.77 × 10⁻⁶ Ω |
Manufacturing Process
Explosion Bonding
A copper rod is inserted into a titanium tube. Controlled explosive energy bonds the titanium and copper metallurgically, forming a high-strength composite bar.
Hot Rolling Process
The bonded bar is hot-rolled to the required diameter and dimensional tolerance.
Quality Control
Non-destructive testing (NDT) is conducted to ensure:
Strong metallurgical bonding
No delamination
No internal defects
Reliable structural integrity
Advantages
Efficient Energy Consumption
Low resistance enables smoother current flow and reduces energy loss.
Superior Durability
Titanium cladding extends service life to more than 10 times compared with conventional materials in corrosive environments.
Reliable Bonding
Explosion + rolling process ensures permanent bonding and prevents liquid penetration or separation.
Applications
Cathodic Protection Systems
Seawater pipeline protection
Offshore platforms
Submerged metal structures
Electrochemical Industry
High-conductivity anodes
Electrolytic systems
Seawater Desalination Plants
Long-life, corrosion-resistant electrode systems
Packaging
Inner Packing:
Soft paper or plastic bag
Outer Packing:
Wooden case (customized packaging available)
