Tubular Titanium MMO Anode
Application:Buried with Coke breeze backfill
Anode Material:Titanium substrate (ASTM B338) coated with Mixed Metal Oxide
MMO:Coating
Thickness:Minimum 6.0 micron (coating weight min. 20 gram / m2)
Coating:Consumption
Rate:Max 1 mg / Amp year
Required Anode Cur.
Density:100 Amps/m2 (at soil + coke breeze)
Anode Current Output:8.0 Amps / pcs for 30 years
Anode Dimension:Diameter 25.4 mm x 1000 mmmm, nominal surface area: 80mm2
Life time:30 years (at current output max 8.0 Amps)
Product Introduction
ASTM F2063 Nitinol wire is a high-performance nickel-titanium (NiTi) shape memory alloy, composed of approximately equal parts nickel and titanium. Originally developed at the Naval Ordnance Laboratory (NOL), Nitinol is renowned for its unique shape memory effect and superelasticity, making it an advanced functional material widely used in medical, industrial, and high-tech applications.
Key Features
Shape Memory Effect
Deforms at low temperature and fully recovers its original shape when heated above the transformation temperature.
Superelasticity (Pseudoelasticity)
Capable of large reversible deformation without permanent damage.
Excellent Biocompatibility
Non-toxic and highly compatible with human tissue, ideal for medical implants.
High Corrosion Resistance
Superior resistance compared to stainless steel, suitable for harsh environments.
High Strength & Fatigue Resistance
Performs reliably under cyclic loading and demanding conditions.
Low Thermal Conductivity
Suitable for applications requiring thermal insulation properties.
Specifications
Material: Nitinol (Ni: 54.5%–57%, Ti: Balance)
Standard: ASTM F2063 / GB 24627-2009
Diameter Range: 0.01 mm – 7.0 mm
Transformation Temperature (Af): -45°C to 90°C
Surface Finish: Black oxide / Pickled / Polished / Ground
Forms Available: Straight wire, coil, spring, custom shapes
Mechanical Properties
Tensile Strength: ≥ 850 MPa
Yield Strength: 195 – 690 MPa
Elongation: 25% – 50%
Applications
Medical Devices: Stents, guidewires, orthodontic wires, surgical instruments
Aerospace & Robotics: Actuators, connectors, adaptive structures
Industrial Use: Sensors, couplings, smart materials
Consumer & Education: Shape memory demonstrations, research, and innovative designs
Quality Assurance
Full inspection of raw materials, semi-finished, and finished products
Strict process control and production traceability
Compliance with international standards
Sample available before bulk order
Advantages
Long service life
Stable and repeatable performance
Customizable transformation temperature and dimensions
Reliable performance in extreme environments
