Titanium Filler Rod

Titanium Filler Rods are high-performance welding consumables designed for joining titanium and titanium alloy components in demanding industrial applications. They offer excellent corrosion resistance, high strength-to-weight ratio, and reliable metallurgical performance when used with appropriate welding procedures and shielding conditions.

Changsheng Titanium supplies titanium filler rods in Grade 5 (Ti-6Al-4V) and Grade 9 (Ti-3Al-2.5V), suitable for precision welding processes including Gas Tungsten Arc Welding (GTAW/TIG) and Plasma Arc Welding (PAW).

Filler rods can be supplied in straight lengths or according to customer-specified dimensions, with material certification and inspection documentation available upon request.

Available Material Grades

Grade 5 – Ti-6Al-4V

Grade 5 titanium alloy is one of the most widely used alpha-beta titanium alloys, offering an excellent combination of strength, low density, fatigue resistance, and corrosion resistance.

Key characteristics:

High strength-to-weight ratio

Excellent fatigue performance

Good corrosion resistance

Heat-treatable alpha-beta titanium alloy

Suitable for demanding structural applications

Widely used in aerospace, industrial, and high-performance applications

Grade 9 – Ti-3Al-2.5V

Grade 9 titanium alloy is a near-alpha titanium alloy developed to provide a balance of strength, ductility, formability, and weldability. It is particularly suitable for applications requiring lightweight construction and reliable performance.

Key characteristics:

Excellent strength-to-weight ratio

Good ductility and formability

Excellent weldability

High corrosion resistance

Good fatigue performance

Suitable for tubing, piping, aerospace, bicycle, and lightweight structural applications

Grade 9 Technical Data

Physical Properties

Property	Typical Value
Density	4.48 g/cm³
Elastic Modulus	Approximately 100 GPa
Shear Modulus	Approximately 44 GPa

Mechanical Properties – Annealed

Property	Requirement / Typical Value
Tensile Strength	≥ 621 MPa (90 ksi)
Typical Tensile Strength	Up to approximately 752 MPa
Condition	Annealed

Actual mechanical properties may vary depending on product size, manufacturing condition, heat treatment, and applicable material specification.

Chemical Composition – Grade 9

Element	Composition, wt.%
Aluminum (Al)	2.5–3.5
Vanadium (V)	2.0–3.0
Iron (Fe)	≤ 0.25
Oxygen (O)	≤ 0.15
Carbon (C)	≤ 0.06
Nitrogen (N)	≤ 0.03
Hydrogen (H)	≤ 0.015
Titanium (Ti)	Balance

Chemical composition is controlled according to the applicable material standard and customer requirements.

Welding Applications

Titanium filler rods are suitable for precision welding applications where low weight, corrosion resistance, and weld integrity are required.

Typical welding processes include:

GTAW / TIG Welding

Plasma Arc Welding (PAW)

Proper shielding with high-purity inert gas and appropriate welding procedures is essential when welding titanium to minimize atmospheric contamination and maintain weld quality.

Typical Applications

Aerospace & Aviation

Aircraft structural components

Aerospace tubing and piping

Engine and compressor components

Lightweight structural assemblies

Industrial Equipment

Heat exchangers

Pressure-containing equipment

Corrosion-resistant process equipment

Chemical processing systems

Industrial piping and welded assemblies

Automotive & Motorsport

High-performance components

Lightweight welded structures

Exhaust and specialized racing applications

Bicycle & Sports Equipment

Grade 9 titanium is particularly suitable for lightweight bicycle frames and other applications requiring a combination of strength, fatigue resistance, ductility, and corrosion resistance.

Chemical, Energy & Marine Industries

Corrosion-resistant welded systems

Chemical processing equipment

Offshore components

Marine structures

Heat-transfer and fluid-handling equipment

Product Supply

Changsheng Titanium can supply titanium filler rods according to specific application and welding requirements.

Available options include:

Grade: Titanium Grade 5 / Grade 9

Material: Ti-6Al-4V / Ti-3Al-2.5V

Rod diameter: Available according to customer requirements

Rod length: Available according to customer requirements

Surface condition: Clean and suitable for welding applications

Packaging: Standard export packaging or customized packaging

Inspection documents: EN 10204 3.1 Material Test Certificate available upon request

Customized dimensions and material specifications can be discussed according to the customer's welding procedure, base material, and application requirements.

Quality & Certification

Each batch can be supplied with relevant material documentation, including chemical composition and mechanical test results where applicable.

Available documentation may include:

Material Test Certificate (EN 10204 3.1)

Chemical composition report

Mechanical test report

Dimensional inspection report

Certificate of conformity

Third-party inspection documents upon request
