Titanium plate and frame heat exchanger

The energy, chemical, electric power, light industrial, petroleum, and other industries all rely heavily on the plate heat exchanger. Titanium plate heat exchanger have numerous advantages, including high strength, low specific gravity, smooth appearance without scaling layer, and excellent heat transfer efficiency. Consequently, it is frequently utilized in aircraft, marine engineering, petroleum, chemical, medical, and other related fields.

Baoji City Changsheng Titanium Co.,Ltd. is a professional company to manufacture plate heat exchanger. The factory has 10sets press machines in workshop, such as 40000T. 15000T .10000T.6000T and so on. Besides, we own more than 10sets punching and shearing equipment, CNC cutting, laser cutting adn some other advanced equipment. It is our constant pursuit to continue to provide new products to customers with the science and technology development. In the full introduction on the basis of absorbing foreign advanced technology. We can supply more than 400 plate models that single plate heat transfer area is from 0.03m2~5m2. Our company is according to tractability management to control the production of plate and equipment. The company's strong manufacturing ability and perfect quality control system provide guarantee for manufacturing first-class product.

Gasketed heat exchange plate

The main components of the heat exchange plate:

1. The plate pack comprises of a number of heat plates, according to the heat transder surface required.

2. Gaskets on the plates ensure that the fluid channels are securely sealed from each other.

3. the direction of flow within the exchanger is determined by the gasket.

4. the frame enclaosing the plate pack is held together with tigthening bolts

5. connections from incoming and outgoing fluids are usually in the fixed frame of the heat exchanger in case of multi pass flow, connections must have to be in the fixed frame and movable frames.

Semi-welded heat exchanger plate

Semi-welded plat heat exchanger is this kind of heat exchanger, whose plates are consist of two plates which is welded by laser along the seal groove, and the two pates are sealed by the gaskets which clamped on the fixed plate and active plate through superposition. the advantages of semi-welded plate heat exchanger is that one side is sealed by welding and the other side is sealed by gasket in order to clean easily. meanwhile, thhere're two special gaskets to seal the two corner pores in the welding side in order to use the fewest seal gaskets.

Mutistage stainless steel heat exchanger plate

Titanium plate heat exchanger is mainly ised in food and medicine environment or relatively severe corrosive environment in accordance iwth the need of working condition of the heating and cooling industry signicantly. it can achieve single sections of the heat exchanger to a liquid will rise to rule temperature and design, changed the past more than one series of solutions.

Titanium plate heat exchanger can acchieve more series ability, high heat transfer capacity, covers small area, and overall outstanding all use stainless steel heat exchanger. the surface will not be oxidation corrosion, and can assembled into a two stage three or more paragraphs to meet customer's technical requirements and thus solve the big area problem caused by meany sets of heat exchanger.
