10mm titanium plate

Titanium alloy plate commonly refers to Ti-6Al-4V (Grade 5 / TC4), a titanium alloy containing 6% aluminum and 4% vanadium. It is the most widely used titanium alloy due to its high strength, excellent corrosion resistance, and outstanding biocompatibility.

The thicknesses 10 mm and 40 mm refer to the plate thickness. These sizes are kept in long-term stock and available for immediate delivery.

Material Description

• Material: Titanium Alloy Grade 5 (Ti-6Al-4V / TC4)

• Standard: ASTM B265

• HS Code: 81089032.90
  (Other titanium plates, sheets, strips, or foil exceeding 0.8 mm in thickness)

• Origin: Domestic material stock

• Export: Worldwide

Available Sizes

• Standard Stock Sizes:

• 10 mm × 1000 mm × 2000 mm

• 40 mm × 1000 mm × 2000 mm

• Thickness Range: 0.02 mm – 60 mm

• Length: 50 mm – 3000 mm

• Width: ≤ 6000 mm

• Custom Sizes: Available upon request

• Manufacturing Technique:

• Hot rolled

• Cold rolled

Key Advantages

• Excellent strength-to-weight ratio

• High resistance to corrosion and oxidation

• Lightweight compared to steel

• Excellent biocompatibility

• Long service life in harsh environments

Applications

10 mm Titanium Plate

10 mm Ti-6Al-4V plate is commonly used in applications requiring high strength with reduced weight, including:

• Aerospace components

• Aircraft engine parts

• Medical and orthopedic implants

• Surgical fixation plates

• Precision tools and machinery

40 mm Titanium Plate

40 mm titanium plate is suitable for heavy-duty and structural applications, such as:

• Marine equipment (propeller shafts, hull components)

• Chemical and petrochemical equipment

• Reactor vessels

• Heat exchangers

• High-load mechanical structures

Industry Coverage

The majority of Grade 5 titanium sheet/plate applications are in:

• Aerospace

• Medical

• Chemical plants

• Tooling and machinery manufacturing

Medical Application Case (Clinical Reference)

Titanium plates have been widely studied in sternal fixation after thymectomy or thymoma excision using transverse sternal incisions.

Clinical Outcomes Summary

• Short-term results:
  Patients treated with 10 mm titanium plate fixation showed significantly better sternal stability compared to steel wire fixation (P < 0.01). Patients were able to resume out-of-hospital activities earlier.

• Long-term results:
  The titanium plate group demonstrated a higher sternal healing rate (P < 0.05), reduced postoperative pain, and a lower incidence of long-term nonunion.

Conclusion

Titanium plate fixation significantly improves postoperative sternal stability, enhances patient mobility, reduces pain, and lowers long-term complication rates compared with traditional steel wire fixation.

Summary

Grade 5 (Ti-6Al-4V) titanium plates with 10 mm and 40 mm thickness offer a combination of high strength, corrosion resistance, and reliability, making them ideal for aerospace, medical, chemical, and marine applications. With stable stock availability and custom sizing, they provide a dependable solution for both standard and demanding engineering requirements.
