MMO Disc Anode
Application area; Cathodic protection of ocean hulls
Specifications:diameter 25/60/100/150mm,and customized requirements.
Product performance:seawater/500-600A / m2 /20 years.
Freshwater and soil at 100A / m2
Coating system: IrO2/Ta2O5 mixed metal oxide & Platinum
Accelerated Life Test Standard: NACE TM0108-2008
Product Introduction
MMO Disc anode are composed of a titanium disc as substrate,which meets ASTM B 265 Grade 1 or 2 standards, and coated with the mixed Metal Oxide & Platinum. MMO coating consists of IrO2/Ta2O5 mixed metal oxide anodes. Direct current transfer is accomplished through the mixed metal oxide catalyst, which is highly conductive, and fully oxidized so that the higher current outputs are possible. It was developed specifically for the rigors of cathodically protecting dam and navigation lock gates. Our disk anodes are designed to operate in fresh, brackish and seawater environments, and other suitable applications include: marine structures, water tanks, and vessels.
Because the titanium disc is naturally passivated by an oxidizing film and the coating has an extremely low consumption rate , the anode remains dimensionally stable over time.With an optional primary seal spacer gasket, it can be used on the inside of pipes, tanks, or other curved surfaces and is suitable for use in all cathodic protection applications. The leading anti-corrosion & uniform current distribution characters, outstanding physical and mechanical properties of titanium, niobium, its Platinized anodes and MMO coated anodes are strongly recommended for Impressed Current Cathodic Protection (ICCP) application.
Specification
Disc Anode Model | Anode Diameter (mm) | Current Rating (A) |
φ25mm | 25 | 0.3 |
φ60mm | 60 | 1.7 |
φ100mm | 100 | 4.7 |
φ150mm | 150 | 10.6 |
This table is for estimating purposes only. Actual values will vary upon site conditions. | ||
Application area; cathodic protection of ocean hulls, etc.
Coating system: IrO2/Ta2O5 mixed metal oxide & Platinum
Accelerated Life Test Standard: NACE TM0108-2008
Accelerated life test:
Test condition | Testing time |
Solution:1mol/L H2SO4, Current:10000A/m2 | Accelerated life> 73 days |
Consumption Rates:
Environment | Max.Anode Current Density |
Seawater | 600 |
Brackish water | 300 |
Fresh water | 100 |
Process:Raw material --- Shearing --- Machining ---welding--- Blasting ---Picking---- coating ---Inspection---Package
About us
Changsheng Titanium, a complete design and fabrication company of mmo disc anodes, established in 2001 is into designing, manufacturing and supply of MMO & Platinum plated Titanium and Niobium anodes for Impressed Current Cathodic Protection (ICCP). Depends upon the customer's requirement, we manufacture the anodes from copper cored titanium and copper cored niobium too. The factory also made'CPCC' connected tubular string anodes; anode tubes; anode strings for offshore platforms protection; civil probe anodes; wire anodes, piggy back anodes, anode flex, canister pack anodes; rod anodes; strip anodes; disc anodes; tank bottom ribbon anodes; mesh ribbon anodes; discrete mesh anodes are also in our scope of production.
